• Aluminium Finned Tube, OD 25-88 mm, WT 0.25-0.45 mm
Aluminium Finned Tube, OD 25-88 mm, WT 0.25-0.45 mm

Short Description

Model No.: LD 13 AFT 01 Hits: 1095

Aluminum Finned Tube manufacturer Landee supplies aluminium finned tube applying to air cooling unit, chemicals, petrochemicals, oil, heat exchangers, etc.
Request a quote Share

Key Specifications / Features

Type: Aluminium Finned Tube.
Product Range:
Finned Tube OD: 25 - 88 mm.
Fin Thickness: 0.25 - 0.45 mm.
Fin pitch: Customized.

Fin material: Aluminium
Base tube material: Any metallic material.

Manufacture:
A core tube is fitted into an aluminium primary tube. This assembly is then fed into the triple-spindle finning machine. Three special multi-disc packs extrude the aluminium tube into helical high fins while reducing the inner diameter to give firm pressure contact with the core tube.

Application:
Air cooling unit.
Product coolers - gas, chemicals, petrochemicals, oil etc.
Heat exchangers.
