Key Specifications / Features
This seamless stainless steel pipe is manufactured from ASTM A312 TP316 stainless steel under the ASME B36.10M standard. With a nominal size of 2.5 inches (DN65), it features a 73 mm outer diameter and a SCH40 wall thickness of 5.16 mm, offered in fixed 3-meter cut lengths. TP316 material provides outstanding resistance to corrosion from chemicals and salty media. It serves process piping systems to carry corrosive fluids, extensively used in chemical plants, petrochemical facilities and marine engineering projects.
- Model No.: LD-20261021-SSP-01
- Hits: 1
- Categories: Stainless Steel Pipe
- Tags: 2-1/2 Inch Pipe , ASME B36.10M Pipes , Seamless Pipe
Detail Information
Pipe Type: Seamless Stainless Steel Pipe
Material: ASTM A312 TP316
Nominal Size: 2.5 inch, 2-1/2 Inch, DN65
Outside Diameter: 73 mm
Wall Thickness: SCH 40, 5.16 mm
Length: 3 meters
Standard: ASME B36.10M
ASTM A312 TP316 seamless stainless steel pipe complying with ASME B36.10M. Nominal size 2.5 inch, outside diameter 73 mm, SCH40 wall thickness 5.16 mm, supplied in fixed 3-meter lengths for process piping.
Ideal for industrial piping to transport corrosive fluids, chemicals, and process media, widely deployed within chemical, petrochemical, and marine engineering sectors.
