Key Specifications / Features
This Ductile Iron Y-Type Strainer is manufactured with an ASTM A536 Grade 65-45-12 body. It features a high-quality AISI 304 stainless steel screen for effective filtration, capable of withstanding pressures up to 500 PSI. The strainer is equipped with ANSI/ASME B1.20.1 threaded ends for secure installation and comes with a painted surface.
- Model No.: LD-20241212-YS-01
- Hits: 18
- Categories: Strainers
- Tags: ASTM A536 Grade 65-45-12 Y Strainer, 500 PSI Y Strainer, Ductile Iron Y Strainer
Detail Information
Product Item: Threaded Y-Type Strainer
Body Material: Ductile Iron ASTM A536 Grade 65-45-12
Screen Material: AISI 304
Connection Ends: Thread to ANSI/ASME B1.20.1
Working Pressure: 500 PSI
Coating: Painting
