Key Specifications / Features
This non-rising stem gate valve keeps the stem stationary during operation, making it ideal for installations with limited vertical clearance. It is manufactured to API 600 standards for bolted bonnet steel gate valves. The body is cast from ASTM A216 WCB carbon steel for high strength and reliability. The wedge combines ASTM A216 WCB with STL6 hardfaced seating surfaces for enhanced wear resistance. The valve measures 6 inches (DN150) and is rated for Class 300 LB (PN50) pressure service.
- Model No.: LD-20260528-GTV-01
- Hits: 0
- Categories: Gate Valves
- Tags: API 600 Gate Valve, ASTM A216 WCB Gate Valve, Non Rising Stem Gate Valve
Detail Information
Product Name: Non-Rising Stem Gate Valve
Type: Non-Rising Stem Gate Valve
Standard: API 600
Size: 6 Inch, DN150, 150 mm
Pressure Class: Class 300 LB, PN50
Body Material: ASTM A216 WCB
Wedge Material: ASTM A216 WCB + STL6
Seat Ring Material: ASTM A105 + 13Cr
End Connection: RF Flanged
