Key Specifications / Features
The Forged Trunnion Mounted Ball Valve is a high-performance industrial valve. Manufactured to API 6D standards, it features a forged ASTM A350 LF2 body. The Devlon seat provides excellent sealing and wear resistance. With a full port design, available in sizes 2 to 12 inches, this Class 600 LB valve has RF flanged ends for secure pipeline integration. It also includes a Double Block and Bleed (DBB) function, enhancing safety and operational efficiency.
- Model No.: LD-20250321-BV-01
- Hits: 58
- Categories: Ball Valves
- Tags: Trunnion Mounted Ball Valve, API 6D Ball Valve, ASTM A350 LF2 Ball Valve
Detail Information
Product Item: Forged Trunnion Mounted Ball Valve, Full Port
Type: Trunnion Mounted Ball Valve (ENP 0.003 Inch)
Design Standard: API 6D
Size: 12 Inch
Pressure: Class 600 LB
Body Material: ASTM A350 LF2
Seat Material: Devlon
Ends: RF Flanged
Operator: Gear Operator
Painting: White Color
Size Range: 2-12 Inch
Features:
- Fire Safe (API 6FA & API 607)
- Double Block and Bleed (DBB)
- Backup Seat
- Grease Injector
