Key Specifications / Features
A leading Swing Check Valve factory in China offers high-quality valves featuring weight and lever mechanisms for reliable flow control. Designed to ASME B16.1 standards, these valves are rated for Class 125 LB flange connections and a working pressure of 300 PSI. They are coated with fusion-bonded epoxy for superior corrosion resistance, ensuring durability and longevity in various applications.
- Model No.: LD-20241210-CV-01
- Hits: 20
- Categories: Check Valves
- Tags: Swing Check Valve, 300 PSI Check Valve
Detail Information
Product Item: Swing Check Valve with Weight & Lever
Connection Ends: Flange to ASME B16.1 Class 125 LB
Working Pressure: 300 PSI
200 PSI and 250 PSI available upon request
Temperature Range: 0℃ to 80℃
Coating: Fusion Bonded Epoxy Coating in accordance with ANSI/AWWA C550
